| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | IGBTType | Voltage-CollectorEmitterBreakdown(Max) | Current-Collector(Ic)(Max) | Current-CollectorPulsed(Icm) | Vce(on)(Max)@VgeIc | Power-Max | SwitchingEnergy | InputType | GateCharge | Td(on/off)@25°C | TestCondition | ReverseRecoveryTime(trr) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RM40N600T7IGBT TRENCH FS 600V 40A TO247-3 |
3,058 | 1.32 |
RFQ |
Tube | - | Active | Trench Field Stop | 600 V | 80 A | 160 A | 2V @ 15V, 40A | 306 W | 1.12mJ (on), 610µJ (off) | Standard | 149 nC | 21ns/203ns | 400V, 40A, 10Ohm, 15V | 151 ns | -55°C ~ 150°C (TJ) | Through Hole | |
|
HGT1S7N60B3DS14 A, 600 V, UFS N-CHANNEL IGBT |
3,365 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 600 V | 14 A | 56 A | 2.1V @ 15V, 7A | 60 W | 160µJ (on), 120µJ (off) | Standard | 30 nC | 26ns/130ns | 480V, 7A, 50Ohm, 15V | 37 ns | -55°C ~ 150°C (TJ) | Surface Mount |
|
STGB20M65DF2IGBT TRENCH 650V 40A D2PAK |
3,654 | 2.38 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | M | Active | Trench Field Stop | 650 V | 40 A | 80 A | 2V @ 15V, 20A | 166 W | 140µJ (on), 560µJ (off) | Standard | 63 nC | 26ns/108ns | 400V, 20A, 12Ohm, 15V | 166 ns | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRGR2B60KDTRLPBFIGBT W/ULTRA-FAST SOFT RECOVERY |
2,173 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | NPT | 600 V | 6.3 A | 8 A | 2.25V @ 15V, 2A | 35 W | 74µJ (on), 39µJ (off) | Standard | 12 nC | 11ns/150ns | 400V, 2A, 100Ohm, 15V | 68 ns | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRGP6640DPBFIGBT W/ULTRAFAST SOFT RECOVERY D |
3,904 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 600 V | 53 A | 72 A | 1.95V @ 15V, 24A | 200 W | 300µJ (on), 840µJ (off) | Standard | 50 nC | 40ns/100ns | 400V, 24A, 10Ohm, 15V | 70 ns | -40°C ~ 175°C (TJ) | Through Hole |
|
IRG4BC20UDPBFIGBT, 13A I(C), 600V V(BR)CES, N |
2,998 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 600 V | 13 A | 52 A | 2.1V @ 15V, 6.5A | 60 W | 160µJ (on), 130µJ (off) | Standard | 41 nC | 39ns/93ns | 480V, 6.5A, 50Ohm, 15V | 37 ns | -55°C ~ 150°C (TJ) | Through Hole |
|
IRGP4063D1-EPBFIGBT W/ULTRAFAST SOFT RECOVERY D |
3,282 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 600 V | 100 A | 192 A | 2.14V @ 15V, 48A | 330 W | 1.4mJ (on), 1.1mJ (off) | Standard | 150 nC | 60ns/160ns | 400V, 48A, 10Ohm, 15V | 80 ns | -40°C ~ 175°C (TJ) | Through Hole |
|
|
HGT1S10N120BNSIGBT, 35A, 1200V, N-CHANNEL, TO- |
3,413 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | NPT | 1200 V | 35 A | 80 A | 2.7V @ 15V, 10A | 298 W | 320µJ (on), 800µJ (off) | Standard | 100 nC | 23ns/165ns | 960V, 10A, 10Ohm, 15V | - | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRG4PC50KDPBF-IRSHORT CIRCUIT RATED ULTRAFAST IG |
3,221 | 1.00 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
IRG4BC20KDSTRLP-IRIGBT 16A, 600V, N CHANNEL |
3,865 | 1.00 |
RFQ |
Datasheet |
Tube | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
IRG4IBC30KDPBF-INFCOPACK IGBT W/ULTRAFAST SOFT REC |
3,662 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 600 V | 17 A | 34 A | 2.7V @ 15V, 16A | 45 W | 600µJ (on), 580µJ (off) | Standard | 100 nC | 60ns/160ns | 480V, 16A, 23Ohm, 15V | 42 ns | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IRG4PC40KDPBF-IRIGBT, 42A, 600V, N-CHANNEL |
2,716 | 1.00 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
IRGB30B60KPBF-INFIGBT, 75A I(C), 600V V(BR)CES, N |
2,594 | 1.00 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
IRG4BC30KDSTRRP-IRSHORT CIRCUIT RATED ULTRAFAST IG |
2,820 | 1.00 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
AUIRGB4062D1-INFIGBT, 59A I(C), 600V V(BR)CES, N |
2,317 | 1.00 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
IRGIB15B60KD1P-IRIGBT W/ULTRAFAST SOFT RECOVERY D |
3,128 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 600 V | 19 A | 38 A | 2.2V @ 15V, 15A | 52 W | 127µJ (on), 334µJ (off) | Standard | 84 nC | 30ns/173ns | 400V, 15A, 22Ohm, 15V | 67 ns | -55°C ~ 175°C (TJ) | Through Hole |
|
|
SGB20N35CLT4-ONIGBT D2PAK SP 350V TR |
2,689 | 1.00 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
AUIRGS30B60K-IRIGBT, 78A I(C), 600V V(BR)CES, N |
2,059 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | NPT | 600 V | 78 A | 120 A | 2.35V @ 15V, 30A | 370 W | 350µJ (on), 825µJ (off) | Standard | 153 nC | 46ns/185ns | 400V, 30A, 10Ohm, 15V | - | -55°C ~ 175°C (TJ) | Surface Mount |
|
AUIRGSL30B60K-IRIGBT, 78A I(C), 600V V(BR)CES, N |
2,228 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | NPT | 600 V | 78 A | 120 A | 2.35V @ 15V, 30A | 370 W | 350µJ (on), 825µJ (off) | Standard | 153 nC | 46ns/185ns | 400V, 30A, 10Ohm, 15V | - | -55°C ~ 175°C (TJ) | Through Hole |
|
IRG4BC40KPBF-IRIGBT, 42A, 600V, N-CHANNEL |
2,964 | 1.00 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
