Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
EFD12/6/3.5-3C96-S EFD CORES 2PC SET Ferroxcube	2,825	0.91	- + RFQ	Datasheet	Bulk	-	Active	EFD	EFD 12 x 6 x 3.5	3C96	-	-	±25%	Ungapped	1490	-	2.5	28.5	11.4	10.7	325	Uncoated	0.244 (6.20mm)
PLT22/16/2.5/S-4F1 PLANAR E CORES Ferroxcube	3,494	0.91	- + RFQ	Datasheet	Bulk	-	Active	PLT	PLT 22 x 16 x 2.5	-	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.114 (2.90mm)
E32/6/20-3C90-A630-E PLANAR E CORES Ferroxcube	2,996	0.92	- + RFQ		Bulk	-	Active	E	E 32 x 6 x 20	3C90	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.250 (6.35mm)
E32/6/20-3C90-A630-P PLANAR E CORES Ferroxcube	2,497	0.92	- + RFQ		Bulk	-	Active	E	E 32 x 6 x 20	3C90	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.250 (6.35mm)
B66229G1000X127 FERRITE CORE E N27 1PC EPCOS - TDK Electronics	3,498	0.92	- + RFQ	Datasheet	Box	E32/16/9	Active	E	E 32 x 16 x 9	N27	-	-	-	Gapped	-	-	-	-	-	-	-	Uncoated	0.646 (16.40mm)
ETD39/20/13-3C97-G1000 ER AND ETD CORES Ferroxcube	3,998	0.92	- + RFQ	Datasheet	Bulk	-	Active	ETD	ETD 39 x 20 x 13	3C97	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.780 (19.80mm)
ETD39/20/13-3C97-G500 ER AND ETD CORES Ferroxcube	3,497	0.92	- + RFQ	Datasheet	Bulk	-	Active	ETD	ETD 39 x 20 x 13	3C97	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.780 (19.80mm)
E41/17/12-3C91-G500 E CORES Ferroxcube	3,489	0.92	- + RFQ	Datasheet	Bulk	-	Active	E	E 41 x 17 x 12	3C91	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.654 (16.60mm)
ETD39/20/13-3F36-G1000 ER AND ETD CORES Ferroxcube	2,956	0.92	- + RFQ	Datasheet	Bulk	-	Active	ETD	ETD 39 x 20 x 13	3F36	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.780 (19.80mm)
ETD39/20/13-3F36-G500 ER AND ETD CORES Ferroxcube	2,313	0.92	- + RFQ	Datasheet	Bulk	-	Active	ETD	ETD 39 x 20 x 13	3F36	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.780 (19.80mm)
ETD39/20/13-3F46-G1000 ER AND ETD CORES Ferroxcube	2,697	0.92	- + RFQ	Datasheet	Bulk	-	Active	ETD	ETD 39 x 20 x 13	3F46	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.780 (19.80mm)
ETD39/20/13-3F46-G500 ER AND ETD CORES Ferroxcube	2,546	0.92	- + RFQ	Datasheet	Bulk	-	Active	ETD	ETD 39 x 20 x 13	3F46	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.780 (19.80mm)
E41/17/12-3C94-G500 E CORES Ferroxcube	2,640	0.92	- + RFQ	Datasheet	Bulk	-	Active	E	E 41 x 17 x 12	3C94	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.654 (16.60mm)
ER14.5/3/7-3C97-A160-S PLANAR ER CORES 2PC SET Ferroxcube	3,562	0.92	- + RFQ	Datasheet	Bulk	-	Active	ER	ER 14.5 x 3 x 7	3C97	-	160 nH	±4%	Gapped	140	-	1.08	19	17.6	17.3	333	Uncoated	0.268 (6.80mm)
ER14.5/3/7-3C97-A63-S PLANAR ER CORES 2PC SET Ferroxcube	3,890	0.92	- + RFQ	Datasheet	Bulk	-	Active	ER	ER 14.5 x 3 x 7	3C97	-	63 nH	±3%	Gapped	54	-	1.08	19	17.6	17.3	333	Uncoated	0.268 (6.80mm)
ER14.5/3/7-3F36-A100-S PLANAR ER CORES 2PC SET Ferroxcube	2,765	0.92	- + RFQ	Datasheet	Bulk	-	Active	ER	ER 14.5 x 3 x 7	3F36	-	100 nH	±3%	Gapped	86	-	1.08	19	17.6	17.3	333	Uncoated	0.268 (6.80mm)
ER14.5/3/7-3F36-A160-S PLANAR ER CORES 2PC SET Ferroxcube	2,156	0.92	- + RFQ	Datasheet	Bulk	-	Active	ER	ER 14.5 x 3 x 7	3F36	-	160 nH	±4%	Gapped	140	-	1.08	19	17.6	17.3	333	Uncoated	0.268 (6.80mm)
ER14.5/3/7-3F46-A100-S PLANAR ER CORES 2PC SET Ferroxcube	2,482	0.92	- + RFQ	Datasheet	Bulk	-	Active	ER	ER 14.5 x 3 x 7	3F46	-	100 nH	±3%	Gapped	86	-	1.08	19	17.6	17.3	333	Uncoated	0.268 (6.80mm)
ER14.5/3/7-3F46-A160-S PLANAR ER CORES 2PC SET Ferroxcube	3,942	0.92	- + RFQ	Datasheet	Bulk	-	Active	ER	ER 14.5 x 3 x 7	3F46	-	160 nH	±4%	Gapped	140	-	1.08	19	17.6	17.3	333	Uncoated	0.268 (6.80mm)
RM4/I-3C95 RM CORES 2PC SET Ferroxcube	2,264	0.92	- + RFQ	Datasheet	Bulk	-	Active	RM	RM 4	3C95	-	-	±25%	Ungapped	-	-	1.69	23.3	13.8	11.5	322	Uncoated	0.421 (10.40mm)
