Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
B64290A0672X087 FERRITE CORE EPCOS - TDK Electronics	2,100	1.23	- + RFQ	Datasheet	Box	T26/14.5/15	Active	Toroid	-	-	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	-
ER23/3.6/13-3C96-A315-S PLANAR ER CORES Ferroxcube	3,465	1.23	- + RFQ	Datasheet	Bulk	-	Active	ER	ER 23 x 3.6 x 13	3C96	-	315 nH	±6%	Gapped	133	-	0.53	26.6	50.2	50	1340	Uncoated	0.142 (3.60mm)
ER23/3.6/13-3C96-A400-S PLANAR ER CORES Ferroxcube	3,022	1.23	- + RFQ	Datasheet	Bulk	-	Active	ER	ER 23 x 3.6 x 13	3C96	-	-	±5%	Gapped	169	-	0.53	26.6	50.2	50	1340	Uncoated	0.142 (3.60mm)
B65541D0000R087 FERRITE CORE P 2.8UH N87 2PCS EPCOS - TDK Electronics	2,717	1.23	- + RFQ	Datasheet	Box	P14/8	Active	P (Pot Core)	P 14 x 8	N87	0.563 (14.30mm)	2.8 µH	-20%, +30%	Ungapped	1630	2200	0.8	20	25	20	500	Uncoated	0.167 (4.25mm)
ER32/6/25-3C95 PLANAR ER CORES Ferroxcube	2,519	1.23	- + RFQ	Datasheet	Bulk	-	Active	ER	ER 32 x 6 x 25	3C95	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.236 (6.00mm)
EQ38/8/25-3C96 EQ CORES Ferroxcube	2,445	1.24	- + RFQ	Datasheet	Bulk	-	Active	EQ	EQ 38 x 8 x 25	3C96	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.315 (8.00mm)
ER54/18/18-3C94 ER AND ETD CORES Ferroxcube	2,668	1.25	- + RFQ	Datasheet	Bulk	-	Active	ER	ER 54 x 18 x 18	3C94	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.720 (18.30mm)
RM8/I-3C97 RM CORES 2PC SET Ferroxcube	2,004	1.25	- + RFQ	Datasheet	Bulk	-	Active	RM	RM 8	3C97	-	-	-	Ungapped	-	-	0.604	38.4	63	55.4	2440	Uncoated	0.646 (16.40mm)
RM8/I-3F36 RM CORES 2PC SET Ferroxcube	2,017	1.25	- + RFQ	Datasheet	Bulk	-	Active	RM	RM 8	3F36	-	-	±25%	Ungapped	-	-	0.604	38.4	63	55.4	2440	Uncoated	0.646 (16.40mm)
RM8/I-3F46 RM CORES 2PC SET Ferroxcube	2,074	1.25	- + RFQ	Datasheet	Bulk	-	Active	RM	RM 8	3F46	-	-	±25%	Ungapped	-	-	0.604	38.4	63	55.4	2440	Uncoated	0.646 (16.40mm)
B65819P0000R087 FERRITE CORE RM 3.3UH N87 2PCS EPCOS - TDK Electronics	2,318	1.25	- + RFQ	Datasheet	Box	RM7/LP	Active	RM	RM 7 LP	N87	-	3.3 µH	-20%, +30%	Ungapped	1360	2200	0.52	23.5	45.3	39.6	1060	Uncoated	0.193 (4.90mm)
EQ38/8/25-3F4 EQ CORES Ferroxcube	3,368	1.25	- + RFQ	Datasheet	Bulk	-	Active	EQ	EQ 38 x 8 x 25	3F4	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.315 (8.00mm)
RM8/I-3C90-A260 RM CORES 2PC SET Ferroxcube	3,884	1.25	- + RFQ		Bulk	-	Active	RM	RM 8	3C90	-	260 nH	±3%	Gapped	126	-	0.44	38.4	63	55.4	2440	Uncoated	0.370 (9.40mm)
RM8/I-3C90-A315 RM CORES 2PC SET Ferroxcube	3,319	1.25	- + RFQ		Bulk	-	Active	RM	RM 8	3C90	-	-	±3%	Gapped	153	-	0.604	38.4	63	55.4	2440	Uncoated	0.646 (16.40mm)
RM8/I-3C90-A630 RM CORES 2PC SET Ferroxcube	2,942	1.25	- + RFQ		Bulk	-	Active	RM	RM 8	3C90	-	630 nH	±5%	Gapped	310	-	0.44	38.4	63	55.4	2440	Uncoated	0.370 (9.40mm)
RM8/I-3C91-A160 RM CORES 2PC SET Ferroxcube	2,755	1.25	- + RFQ	Datasheet	Bulk	-	Active	RM	RM 8	3C91	-	160 nH	±3%	Gapped	78	-	0.44	38.4	63	55.4	2440	Uncoated	0.370 (9.40mm)
RM8/I-3C91-A250 RM CORES 2PC SET Ferroxcube	2,946	1.25	- + RFQ	Datasheet	Bulk	-	Active	RM	RM 8	3C91	-	250 nH	±3%	Gapped	120	-	0.44	38.4	63	55.4	2440	Uncoated	0.370 (9.40mm)
RM8/I-3C91-A400 RM CORES 2PC SET Ferroxcube	2,465	1.25	- + RFQ	Datasheet	Bulk	-	Active	RM	RM 8	3C91	-	400 nH	±3%	Gapped	194	-	0.44	38.4	63	55.4	2440	Uncoated	0.370 (9.40mm)
RM8/I-3C94-A160 RM CORES 2PC SET Ferroxcube	3,487	1.25	- + RFQ	Datasheet	Bulk	-	Active	RM	RM 8	3C94	-	-	±3%	Gapped	78	-	0.604	38.4	63	55.4	2440	Uncoated	0.646 (16.40mm)
RM8/I-3C94-A250 RM CORES 2PC SET Ferroxcube	2,042	1.25	- + RFQ	Datasheet	Bulk	-	Active	RM	RM 8	3C94	-	-	±3%	Gapped	121	-	0.604	38.4	63	55.4	2440	Uncoated	0.646 (16.40mm)
