Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
B65803J0100A087 FERRITE CORE EPCOS - TDK Electronics	2,987	1.27	- + RFQ	Datasheet	Box	RM4	Active	RM	RM 4	N87	-	-	-	Gapped	-	2200	1.7	22	13	11.3	286	Uncoated	0.413 (10.50mm)
B65803J0160J087 FERRITE CORE EPCOS - TDK Electronics	3,262	1.27	- + RFQ	Datasheet	Box	RM4	Active	RM	RM 4	N87	-	-	-	Gapped	-	2200	1.7	22	13	11.3	286	Uncoated	0.413 (10.50mm)
B65803J0063A087 FERRITE CORE EPCOS - TDK Electronics	3,350	1.27	- + RFQ	Datasheet	Box	RM4	Active	RM	RM 4	N87	-	-	-	Gapped	-	2200	1.7	22	13	11.3	286	Uncoated	0.413 (10.50mm)
6295280121 95 RM CORE SET Fair-Rite Products Corp.	2,962	1.27	- + RFQ	Datasheet	Bulk	-	Active	RM	-	95	-	-	±25%	Ungapped	-	3000	53	47.9	89.8	88.4	4306	Uncoated	0.366 (9.30mm)
E38/8/25-3C90 PLANAR E CORES Ferroxcube	2,760	1.27	- + RFQ		Bulk	-	Active	E	E 38 x 8 x 25	3C90	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.325 (8.26mm)
B65531D0040A033 FERRITE CORE P 40NH M33 2PCS EPCOS - TDK Electronics	2,916	1.28	- + RFQ	Datasheet	Box	P11/7	Active	P (Pot Core)	P 11 x 7	M33	0.445 (11.30mm)	40 nH	±3%	Gapped	32	750	1	15.9	15.9	-	253	Uncoated	0.130 (3.30mm)
E42/21/20-3C90-G100 E CORES Ferroxcube	2,299	1.28	- + RFQ	Datasheet	Bulk	-	Active	E	E 42 x 21 x 20	3C90	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.827 (21.00mm)
E42/21/20-3C91-G200 E CORES Ferroxcube	2,748	1.28	- + RFQ	Datasheet	Bulk	-	Active	E	E 42 x 21 x 20	3C91	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.827 (21.00mm)
E42/21/20-3C94-G200 E CORES Ferroxcube	2,842	1.28	- + RFQ	Datasheet	Bulk	-	Active	E	E 42 x 21 x 20	3C94	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.827 (21.00mm)
ER23/3.6/13-3C97-S PLANAR ER CORES Ferroxcube	3,967	1.28	- + RFQ	Datasheet	Bulk	-	Active	ER	ER 23 x 3.6 x 13	3C97	-	-	±25%	Ungapped	-	-	0.53	26.6	50.2	50	1340	Uncoated	0.142 (3.60mm)
ER23/3.6/13-3F36-S PLANAR ER CORES Ferroxcube	3,310	1.28	- + RFQ	Datasheet	Bulk	-	Active	ER	ER 23 x 3.6 x 13	3F36	-	-	±25%	Ungapped	-	-	0.53	26.6	50.2	50	1340	Uncoated	0.142 (3.60mm)
ER23/3.6/13-3F46-S PLANAR ER CORES Ferroxcube	2,648	1.28	- + RFQ	Datasheet	Bulk	-	Active	ER	ER 23 x 3.6 x 13	3F46	-	1.6 µH	±25%	Ungapped	670	-	0.53	26.6	50.2	50	1340	Uncoated	0.142 (3.60mm)
B65807J0160A041 FERRITE CORE EPCOS - TDK Electronics	3,309	1.28	- + RFQ	Datasheet	Box	RM6	Active	RM	RM 6	N41	-	-	-	Gapped	-	2800	0.78	28.6	36.6	31	1050	Uncoated	0.246 (6.25mm)
B65807J0315J041 FERRITE CORE EPCOS - TDK Electronics	2,601	1.28	- + RFQ	Datasheet	Box	RM6	Active	RM	RM 6	N41	-	-	-	Gapped	-	2800	0.78	28.6	36.6	31	1050	Uncoated	0.246 (6.25mm)
B65807J0630J041 FERRITE CORE EPCOS - TDK Electronics	3,080	1.28	- + RFQ	Datasheet	Box	RM6	Active	RM	RM 6	N41	-	-	-	Gapped	-	2800	0.78	28.6	36.6	31	1050	Uncoated	0.246 (6.25mm)
B65525J0000R001 FERRITE CORE EPCOS - TDK Electronics	3,595	1.28	- + RFQ	Datasheet	Box	ER11/5	Active	ER	ER 11 x 5	K1	-	-	-	-	-	80	1.1	14.1	12.4	10.3	174	Uncoated	0.098 (2.50mm)
P18/11-3C90 P CORES 2PC SET Ferroxcube	2,735	1.28	- + RFQ		Bulk	-	Active	P	P 18 x 11	3C90	0.724 (18.40mm)	3.4 µH	±25%	Ungapped	1600	-	0.597	25.8	43.3	36	1120	Uncoated	0.417 (10.60mm)
PQ26/20-3C94 PQ CORES 2PC SET Ferroxcube	2,888	1.28	- + RFQ	Datasheet	Bulk	-	Active	PQ	PQ 26 x 20	3C94	-	-	±25%	Ungapped	1640	-	0.372	45	121	109	5470	Uncoated	0.795 (20.20mm)
B66308A2001X FERRITE CORES EPCOS - TDK Electronics	2,239	1.29	- + RFQ		Tape & Reel (TR)	B66308	Not For New Designs	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
B65541D0160A048 FERRITE CORE P 160NH N48 2PCS EPCOS - TDK Electronics	2,528	1.29	- + RFQ	Datasheet	Box	P14/8	Active	P (Pot Core)	P 14 x 8	N48	0.563 (14.30mm)	160 nH	±3%	Gapped	102	-	0.8	20	25	20	500	Uncoated	0.167 (4.25mm)
