Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
E58/11/38-3C97-A400-P PLANAR E CORES Ferroxcube	3,051	3.95	- + RFQ	Datasheet	Bulk	-	Active	E	E 58 x 11 x 38	3C97	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.413 (10.50mm)
E58/11/38-3C97-A630-E PLANAR E CORES Ferroxcube	3,893	3.95	- + RFQ	Datasheet	Bulk	-	Active	E	E 58 x 11 x 38	3C97	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.413 (10.50mm)
E58/11/38-3C97-A630-P PLANAR E CORES Ferroxcube	2,314	3.95	- + RFQ	Datasheet	Bulk	-	Active	E	E 58 x 11 x 38	3C97	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.413 (10.50mm)
E58/11/38-3F36-A400-E PLANAR E CORES Ferroxcube	3,891	3.95	- + RFQ	Datasheet	Bulk	-	Active	E	E 58 x 11 x 38	3F36	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.413 (10.50mm)
E58/11/38-3F36-A400-P PLANAR E CORES Ferroxcube	2,511	3.95	- + RFQ	Datasheet	Bulk	-	Active	E	E 58 x 11 x 38	3F36	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.413 (10.50mm)
E58/11/38-3F36-A630-E PLANAR E CORES Ferroxcube	2,882	3.95	- + RFQ	Datasheet	Bulk	-	Active	E	E 58 x 11 x 38	3F36	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.413 (10.50mm)
E58/11/38-3F36-A630-P PLANAR E CORES Ferroxcube	2,878	3.95	- + RFQ	Datasheet	Bulk	-	Active	E	E 58 x 11 x 38	3F36	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.413 (10.50mm)
B66506P0000X195 FERRITE CORE I N95 1PC EPCOS - TDK Electronics	3,745	3.95	- + RFQ	Datasheet	Box	I30/2.7/20	Active	I	I 30 x 3	N95	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.106 (2.70mm)
9595545402 95 ETD CORE SET Fair-Rite Products Corp.	2,091	3.96	- + RFQ	Datasheet	Bulk	-	Active	ETD	-	95	-	-	±25%	Ungapped	-	3000	47	125.6	265	240	33300	Uncoated	-
UR59/36/17-3C90 UR CORES Ferroxcube	3,221	3.96	- + RFQ	Datasheet	Bulk	-	Active	UR	UR 59 x 36 x 17	3C90	-	-	-	-	-	-	-	-	-	-	-	Uncoated	1.409 (35.80mm)
B65671D0000Y038 FERRITE CORE P 22UH T38 2PCS EPCOS - TDK Electronics	3,830	3.98	- + RFQ	Datasheet	Box	P26/16	Active	P (Pot Core)	P 26 x 16	T38	1.024 (26.00mm)	22 µH	-30%, +40%	Ungapped	6480	2300	0.4	37.2	93	76.5	3460	Uncoated	0.321 (8.15mm)
TX40/24/16-3E65 FERRITE CORES ROUND Ferroxcube	3,486	4.00	- + RFQ	Datasheet	Bulk	-	Active	Toroid	TX 40 x 24 x 16	-	1.640 (41.65mm)	-	±25%	Ungapped	5200	-	0.769	96.3	125	-	12100	Epoxy	0.673 (17.10mm)
B65701D0000R030 FERRITE CORE P 11.5UH N30 2PCS EPCOS - TDK Electronics	3,940	4.02	- + RFQ	Datasheet	Box	P30/19	Active	P (Pot Core)	P 30 x 19	N30	1.200 (30.50mm)	11.5 µH	-20%, +30%	Ungapped	2900	4300	0.33	45	136	-	6120	Uncoated	0.374 (9.50mm)
B66395G2500X127 FERRITE CORE EPCOS - TDK Electronics	3,242	4.03	- + RFQ	Datasheet	Box	ETD54/28/19	Active	ETD	ETD 54 x 28 x 19	N27	-	-	-	Gapped	-	2000	0.45	127	280	280	35600	Uncoated	1.094 (27.80mm)
ETD59/31/22-3C95-G200 ER AND ETD CORES Ferroxcube	2,392	4.06	- + RFQ	Datasheet	Bulk	-	Active	ETD	ETD 59 x 31 x 22	3C95	-	-	-	-	-	-	-	-	-	-	-	Uncoated	1.220 (31.00mm)
P30/19-3C90 P CORES 2PC SET Ferroxcube	2,232	4.06	- + RFQ		Bulk	-	Active	P	P 30 x 19	3C90	1.181 (30.00mm)	6.5 µH	±25%	Ungapped	1700	-	0.33	45.2	137	116	6190	Uncoated	0.740 (18.80mm)
RM12/I-3C94-E250 RM CORES 2PC SET Ferroxcube	3,983	4.06	- + RFQ	Datasheet	Bulk	-	Active	RM	RM 12	3C94	-	250 nH	±3%	Gapped	77	-	0.388	56.6	146	125	8340	Uncoated	0.965 (24.50mm)
B65847A0000Y038 FERRITE CORE EP 18.7UH T38 2PCS EPCOS - TDK Electronics	3,222	4.10	- + RFQ	Datasheet	Box	EP20	Active	EP	EP 20	T38	-	18.7 µH	-30%, +40%	Ungapped	7630	2300	0.51	40	78	60	3120	Uncoated	0.425 (10.80mm)
RM12/I-3F36-A400 RM CORES 2PC SET Ferroxcube	2,160	4.14	- + RFQ	Datasheet	Bulk	-	Active	RM	RM 12	3F36	-	400 nH	±3%	Gapped	123	-	0.388	56.6	146	125	8340	Uncoated	0.965 (24.50mm)
RM12/I-3F36-A630 RM CORES 2PC SET Ferroxcube	3,136	4.14	- + RFQ	Datasheet	Bulk	-	Active	RM	RM 12	3F36	-	630 nH	±3%	Gapped	194	-	0.388	56.6	146	125	8340	Uncoated	0.965 (24.50mm)
